Glass Beveling Machine for Big Size

Beveling machine for big glass size.

Item NO.:
SY-9-45
Color:
Steel Blue or Customized
Lead Time:
25 days
Warranty:
1 Year

contact now

Product Details

SY - 9-45 glass straight line edging machine is use for cutting grinding flat glass of different thickness of the straight edge and bevel edge, this product with second abrasive wheel of coarse grinding, third abrasive fine grinding, One abrasive wheel fix bottom. three abrasive wheels of pneumatic polishing process of disposable, adjustable front guide to change process glass thickness. adjust the processing speed with CVT. Simple operation, small shaking, good rigidity, Finished beveling edge can same as the mirror flat. This is a indispensable machine for glass processing

Machine parameter

Pocessing bevel degree: 3-20°

Feeding Speed: 0.3m/min-3m/min

Min. precessing sizes: 100mmx 100mm

Max. Precessing size: 2000*2000mm

The prcessing glass thichness: 3-19mm

Max width of bevel: 30mm

The size of the machines（L*W*H): 8000 X 1500X2300mm

power: 18KW

Weight: 5000KG

Configuration

1 Transom: iron founding

2 Pressure plate: high quality steel and rubber

3 Motor: Domestic

4 Electric: GreatWall or Zhengtai

5 Drive: Double output gear lever and sproket.

6 Grinding wheel: Imported Italian
